FRONT FENDER (MODEL K1)

DR-Z400S 2004 (K4) USA (E03) DRZ400S DR Z400S

Front fender (model k1) diagram DR-Z400S 2004 (K4) USA (E03) DRZ400S DR Z400S

prices are in EUR

ref

part #

description

quantity

1-1

5181132E0030H
ref: 1-1

COVER,HEADLAMP

€ 78.50

1-2

5181132E00YR1
ref: 1-2

COVER,HEADLAMP

€ 83.00

2-1

6817144B008YM
ref: 2-1

EMBLEM,HEADLAMP COVER

€ 11.00

2-2

6817144B00FR3
ref: 2-2

EMBLEM,SUZUKI

€ 6.00

0214206123
ref: 3
02142-0612A

SCREW 6X12

€ 2.00

0214205123
ref: 4
02142-0512A

SCREW 5X12

€ 1.50

0916906033
ref: 5

WASHER

€ 1.50

6-1

5311127C22YJ4
ref: 6-1

FENDER,FR

€ 86.00

6-2

5311127C22YR1
ref: 6-2
53111-27C22-YU1

FENDER,FRONT

€ 53.00

0911606170
ref: 7

BOLT(6X16)

€ 3.00

0916906073
ref: 8

WASHER

€ 4.00
