FRONT FENDER

DL1000 VSTROM 2008 (K8) USA (E03)

Front fender diagram DL1000 VSTROM 2008 (K8) USA (E03)

FRONT FENDER DL1000 VSTROM 2008 (K8) USA (E03)

FRONT FENDER DL1000 VSTROM 2008 (K8) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5311106G00YAY
ref: 1

FENDER,FR

€ 343.50

2

0913906121
ref: 2

SCREW(6X16)

€ 5.50

3

5312206G00
ref: 3

NUT,FR FENDER

€ 4.00

4

015470645B
ref: 4

BOLT

€ 3.00

5

015470630B
ref: 5

BOLT

€ 3.00
