CAM CHAIN

DR250S 1982 (Z)

Cam chain diagram DR250S 1982 (Z)

CAM CHAIN DR250S 1982 (Z)

CAM CHAIN DR250S 1982 (Z)

prices are in EUR

ref

part #

description

quantity

1

1276038200
ref: 1
112LE

CHAIN,CAMSHAFT DRIVE

€ 109.50

2

1277138200
ref: 2

GUIDE,CAM CHAIN

€ 34.00

3

1281138200
ref: 3

TENSIONER,CAM CHAIN

€ 31.50

4

1281232410
ref: 4

BOLT,CAM CHAIN TENSIONER

€ 3.50

5

0916808008
ref: 5

GASKET 8.2X14X1 (NAS)

€ 1.00

6

1283038210
ref: 6

ADJUSTER ASSEMBLY,TENSIONER

€ 91.00

7

1283838200
ref: 7

GASKET,ADJUSTER CAP (MCA)

€ 3.00

8

1283738200
ref: 8

GASKET,TENSIONER ADJUSTER (MCA)

€ 3.50

9

1283938200
ref: 9

PLUG,ADJUSTER

€ 2.00

10

0910606029
ref: 10

BOLT

€ 3.00
