HEADLAMP
DR500 1981 (X) USA (E03)
Headlamp diagram DR500 1981 (X) USA (E03)
HEADLAMP DR500 1981 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3510037200
ref: 1
HEADLAMP ASSEMBLY
€ 99.00
2
3512137200
ref: 2
LAMP UNIT
€ 82.50
3
0947106022
ref: 3
BULB(6V15/15W/STANLEY,A3598HA)
€ 6.50
4
3517143020
ref: 4
35171-09X50
SOCKET,HEADLAMP
€ 12.50
5
3515435300
ref: 5
SPRING,HEAD LAMP ADJUSTER
€ 3.00
6
3515135301
ref: 6
35623-09400
SCREW,HEADLAMP ADJUST
€ 2.50
7
3512837200
ref: 7
SPRING
€ 3.50
8
3515437200
ref: 8
09132-03002
SPRING,HEADLAMP ADJUST
€ 1.50
