FUEL TANK (MODEL Z)

GN250 1982 (Z) USA (E03)

Fuel tank (model z) diagram GN250 1982 (Z) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

4410038300019
ref: 1-1
44110-38302-YD8

TANK ASSEMBLY,FUEL

€ 346.00

1-2

441003830003F
ref: 1-2
44110-38302-YD8

TANK ASSEMBLY,FUEL

€ 346.00

6811038300764
ref: 2

TAPE SET,FUEL TANK

€ 0.00

6811137300
ref: 3

EMBLEM,FUEL TANK

€ 14.00

0213203065
ref: 4
02122-0306B

SCREW 3X6

€ 2.00

4420030704
ref: 5
44200-30830

CAP SET,FUEL TANK

€ 112.00

0932910016
ref: 6

CUSHION

€ 3.00

4454138200
ref: 7

CUSHION,TANK UPR FR

€ 6.00

4454238300
ref: 8

CUSHION,TANK RR NO.1

€ 8.00

0932010022
ref: 9

CUSHION

€ 2.50

0918006067
ref: 10

SPACER(6.5X10.5X22.5)

€ 2.50

0916006012
ref: 11
09160-06054

WASHER(6,5X22X1.6)

€ 2.00

0910006033
ref: 12

BOLT(6X35)

€ 12.50
