HEADLAMP (E4)

GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41

Headlamp (e4) diagram GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41

HEADLAMP (E4) GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
HEADLAMP (E4) GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
HEADLAMP (E4) GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
prices are in EUR
ref
part #
description
quantity
1
3510029630999
ref: 1
HEADLAMP ASSY
€ 0.00
2
3511129640
ref: 2
RIM
3511129640
€ 38.50
3
3512127650
ref: 3
UNIT
€ 77.00
4
3517136640
ref: 4
SOCKET
€ 0.00
5
3517228660
ref: 5
CLAMP,HEADLAMP
3517228660
€ 7.00
6
3517233630
ref: 6
SPRING
3517233630
€ 4.00
7
3611828660
ref: 7
SOCKET
3611828660
€ 11.50
8
0947106047
ref: 8
EXECUTED LOCALLY
BULB (6V,4W)
€ 0.00
9
0947106032
ref: 9
EXECUTED LOCALLY
BULB (6V,25/25W)
€ 0.00
