REAR BRAKE

GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41

Rear brake diagram GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41

REAR BRAKE GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
REAR BRAKE GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
REAR BRAKE GP125 1979 (N) (E01 E02 E04 E06 E13 E17 E18 E21 E22 E24 30 35 41
prices are in EUR
ref
part #
description
quantity
1
4311039600
ref: 1
PEDAL,BRAKE
4311039600
€ 281.00
2
0944831013
ref: 2
SPRING
0944831013
€ 3.00
3
0916015002
ref: 3
WASHER(15.5X26X2.3)
0916015002
€ 2.00
4
0411130308
ref: 4
COTTER PIN
0411130308
€ 1.50
5
4330039100
ref: 5
ROD ASSY, REAR BRAKE
€ 16.00
6
0944009004
ref: 6
SPRING
0944009004
€ 2.00
7
0920911002
ref: 7
PIN(11X18)
0920911002
€ 2.00
8
0915006001
ref: 8
NUT
0915006001
€ 3.50
9
0832221058
ref: 9
WASHER
€ 2.50
10
0411120208
ref: 10
PIN 20X20
0411120208
€ 1.50
11
0832221068
ref: 11
WASHER
0832221068
€ 2.00
