CRANKCASE COVER
GS450SU 1988 (J) GERMANY (E22)
Crankcase cover diagram GS450SU 1988 (J) GERMANY (E22)
CRANKCASE COVER GS450SU 1988 (J) GERMANY (E22)
×
prices are in EUR
ref
part #
description
quantity
1
1134144111
ref: 1
COVER,CLUTCH
€ 135.50
2
1148244100
ref: 2
GASKET,CLUTCH COVER (MCA)
€ 17.50
3
0920613001
ref: 3
PIN
€ 2.50
4
0154706555
ref: 4
BOLT (6X55)
€ 3.00
5
0154706354
ref: 5
BOLT 6X35
€ 3.00
6
0154706254
ref: 6
BOLT 6X25
€ 2.50
7
1197044110
ref: 7
GAUGE,OIL LEVEL
€ 20.50
8
0928027002
ref: 8
O-RING
€ 3.00
9
0924714012
ref: 9
PLUG (14X12)
€ 3.50
10
0916814004
ref: 10
GASKET(14X19.2X2) (NAS)
€ 2.50
11
1138144111
ref: 11
COVER,CONTACT
€ 41.50
12
1149144110
ref: 12
GASKET,CONTACT (MCA)
€ 4.50
13
0154705165
ref: 13
BOLT 5X16
€ 2.00
14
6823344100
ref: 14
EMBLEM,MAGNETO COVER
€ 15.50
15
1135144112
ref: 15
COVER,MAGNETO
€ 171.00
16
1148344101
ref: 16
GASKET,MAGNETO COVER (MCA)
€ 12.50
17
0920613001
ref: 17
PIN
€ 2.50
18
0154706354
ref: 18
BOLT 6X35
€ 3.00
19
6823344100
ref: 19
EMBLEM,MAGNETO COVER
€ 15.50
20
1136144111
ref: 20
COVER, ENGINE SPROCKET
€ 86.00
21
0835111009
ref: 21
NIPPLE
€ 32.00
22
0421109129
ref: 22
PIN
€ 2.00
23
0154706654
ref: 23
BOLT
€ 2.00
24
0154706505
ref: 24
BOLT 6X50
€ 3.50
25
0154706404
ref: 25
BOLT 6X40
€ 3.00
26
1138244111
ref: 26
COVER,STARTER MOTOR
€ 20.50
27
0154705084
ref: 27
BOLT
€ 2.50
28
1138744110
ref: 28
CAP, CLUTCH RELEASE
€ 10.00
29
0213205124
ref: 29
SCREW
€ 2.00
30
3782033200
ref: 30
SWITCH ASSEMBLY
€ 29.00
