MUFFLER
GS450SU 1988 (J) GERMANY (E22)
Muffler diagram GS450SU 1988 (J) GERMANY (E22)
MUFFLER GS450SU 1988 (J) GERMANY (E22)
×
prices are in EUR
ref
part #
description
quantity
1
1418111020
ref: 1
GASKET,EXHAUST PIPE (NAS)
€ 8.00
2
0110708408
ref: 2
BOLT 8X40
€ 3.00
3
0832121088
ref: 3
LOCK WASHER
€ 2.00
4
1430144450
ref: 4
MUFFLER ASSY,R
€ 270.50
5
1430244450
ref: 5
MUFFLER ASSY,L
€ 270.50
6
0940235601
ref: 6
CLAMP
€ 5.00
7
0151706258
ref: 7
BOLT
€ 2.50
8
1478044401
ref: 8
COVER,MUFFLER
€ 25.00
9
1479044401
ref: 9
COVER,MUFFLER
€ 33.50
10
1478544100
ref: 10
CLAMP,MUFFLER COVER
€ 8.50
11
0211205168
ref: 11
SCREW
€ 2.50
12
0211206108
ref: 12
SCREW
€ 1.50
13
0832121067
ref: 13
WASHER,LOCK
€ 2.50
14
0832221067
ref: 14
WASHER
€ 2.00
