FRAME COVER (MODEL K1)

ref

part #

description

quantity

1-1

4711001DJ0YM7
ref: 1-1

COVER,FRAME,R(BLUE)

€ 198.00

1-2

4711001DJ0YC2
ref: 1-2

COVER,FRAME,R(BLUE)

€ 212.50

2-1

6813501D50FT7
ref: 2-1

TAPE,FRAME COVER,R

€ 19.50

2-2

6813501D50FT5
ref: 2-2

TAPE,FRAME COVER,R

€ 20.00

3

6813101D40FN3
ref: 3

EMBLEM,FRAME COVER

€ 13.00

4-1

4721001DJ0YM7
ref: 4-1

COVER,FRAME,L(BLUE)

€ 209.00

4-2

4721001DJOYC2
ref: 4-2

COVER, FRAME LH (BLUE) E28

€ 0.00

5-1

6814501D50FT7
ref: 5-1

TAPE,FRAME COVER,L

€ 20.00

5-2

6814501D50FT5
ref: 5-2

TAPE,FRAME COVER,L

€ 14.50

6

6813101D40FN3
ref: 6

EMBLEM,FRAME COVER

€ 13.00

7

0911606010
ref: 7

BOLT(6X20)

€ 2.00

8

0918006263
ref: 8

SPACER(6.5X9X9)

€ 2.00

9

0932009016
ref: 9

CUSHION

€ 2.50

10-1

4731001D50YM7
ref: 10-1

COVER,FRAME CTR

€ 43.50

10-2

4731001D50YC2
ref: 10-2

COVER,FRAME CTR

€ 44.00

11-1

6816501D001ZY
ref: 11-1

EMBLEM,SUZUKI

€ 0.00

11-2

6816501D00YD8
ref: 11-2

EMBLEM."SUZUKI"

€ 8.00

12

4732101DA0
ref: 12
47321-01DA0-NE2

COVER, FRAME LOWER

€ 31.00

13

0354104103
ref: 13
03541-0410A

SCREW

€ 1.50

14

0932008018
ref: 14

CUSHION

€ 4.00
