STARTER CLUTCH

GS500F 2007 (K7) USA (E03)

Starter clutch diagram GS500F 2007 (K7) USA (E03)

STARTER CLUTCH GS500F 2007 (K7) USA (E03)

STARTER CLUTCH GS500F 2007 (K7) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1261101D00
ref: 1

GEAR,STARTER IDLE

€ 73.50

2

0920613003
ref: 2

PIN(7.4X13X56)

€ 9.00

3

1260044835
ref: 3

CLUTCH SET, STARTER

€ 313.00

4

0926115001
ref: 4

ROLLER(15X13)

€ 3.50

5

0944004015
ref: 5

SPRING

€ 2.50

6

1263331000
ref: 6

PIECE,PUSH

€ 9.00

7

0910608095
ref: 7

BOLT(8X16)

€ 2.50

8

1264945000
ref: 8

SHIM,STARTER CLUTCH HUB

€ 7.00
