FRONT WHEEL
GS850G 1982 (Z) USA (E03)
Front wheel diagram GS850G 1982 (Z) USA (E03)
FRONT WHEEL GS850G 1982 (Z) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5411149400291
ref: 1
CASTING WHEEL,FRONT 2.15
€ 580.00
2
0812363027
ref: 2
BEARING
€ 19.00
3
5473018400
ref: 3
SPACER,FR HUB BEARING
€ 13.00
4
5471149000
ref: 4
AXLE,FR
€ 79.50
5
0831431128
ref: 5
08314-3112A
NUT 12MM
€ 2.00
6
0411130308
ref: 6
04111-3030A
COTTER PIN
€ 1.50
7
5474018402
ref: 7
SPACER,FR AXLE,R
€ 18.50
8
5474149300
ref: 8
SPACER,FR AXLE,R
€ 19.00
9
5474149000
ref: 9
SPACER,FR AXLE,L
€ 16.50
10
0832221128
ref: 10
08322-01127
WASHER
€ 2.00
11
5487145010
ref: 11
DUST SEAL,SPEEDOMETER GEAR BOX
€ 21.00
12
5460018401
ref: 12
54600-18402
BOX ASSEMBLY,SPEEDOMETER GEAR
€ 90.50
13
5921145250
ref: 13
DISC,FR BRAKE,R
€ 149.00
14
5922145250
ref: 14
DISC,FR BRAKE,L
€ 149.00
15
0910008140
ref: 15
BOLT(8X25)
€ 2.00
16
0916908016
ref: 16
WASHER
€ 3.50
17
5510045110
ref: 17
55100-45130
TIRE,FRONT
€ 0.00
18
5522045100
ref: 18
43130-24A40
VALVE ASSEMBLY,WHEEL RIM,J
€ 15.50
19-1
5541145100
ref: 19-1
55412-17G00
BALANCER,WHEEL
€ 7.00
19-2
5541245100
ref: 19-2
BALANCER,WHEEL
€ 4.00
19-3
5541345100
ref: 19-3
55411-00A00-10V
BALANCER,WHEEL
€ 6.50
