CARBURETOR

GSX750EF 1984 (E) (E1 2 4 6 15 16 17 18 21 22 24 25 26 30 34 39)

Carburetor diagram GSX750EF 1984 (E) (E1 2 4 6 15 16 17 18 21 22 24 25 26 30 34 39)

CARBURETOR GSX750EF 1984 (E) (E1 2 4 6 15 16 17 18 21 22 24 25 26 30 34 39)
CARBURETOR GSX750EF 1984 (E) (E1 2 4 6 15 16 17 18 21 22 24 25 26 30 34 39)
CARBURETOR GSX750EF 1984 (E) (E1 2 4 6 15 16 17 18 21 22 24 25 26 30 34 39)
prices are in EUR
ref
part #
description
quantity
1
1320131310
ref: 1
CARBURETOR, LH
€ 344.50
1
1320131320
ref: 1
E18
CARBURETOR, LH
€ 181.50
2
1320231310
ref: 2
CARBURETOR, ML
€ 344.50
2
1320231320
ref: 2
E18
CARBURETOR, ML
€ 0.00
3
1320331310
ref: 3
CARBURETOR, MR
€ 344.50
3
1320331320
ref: 3
E18
CARBURETOR, MR
€ 0.00
4
1320431310
ref: 4
CARBURETOR, RH
€ 368.50
4
1320431320
ref: 4
E18
CARBURETOR, RH
€ 0.00
5
1350031300
ref: 5
DIAPHRAGM,CARBURETOR
1350031300
€ 184.50
5
1350031320
ref: 5
E18
DIAPHRAGM
€ 0.00
6
1339431210
ref: 6
CLIP,NEEDLE
1339431210
€ 3.50
7
1338744030
ref: 7
RING
1338744030
€ 5.00
8
1338944030
ref: 8
HOLDER,GUIDE
1338944030
€ 10.50
9
1350331300
ref: 9
SPRING,DIAPHRAGM
1350331300
€ 8.00
10
1358144030
ref: 10
E RING
1358144030
€ 6.50
11
1338331310
ref: 11
NEEDLE, JET (5D10-3)
€ 13.00
12
1355749200
ref: 12
ML,MR
GASKET
1355749200
€ 7.00
13
1357847070
ref: 13
RH,LH
CAP
1357847070
€ 5.50
14
0831022088
ref: 14
MR
NUT 8MM
0831022088
€ 2.00
15
1360647070
ref: 15
MR
WASHER
1360647070
€ 3.00
16
1357347070
ref: 16
LH
SPRING,THROTTLE SHAFT
1357347070
€ 6.00
17
1355047070
ref: 17
LH
SHAFT,THROTTLE
1355047070
€ 44.50
18
1355045400
ref: 18
ML
SHAFT,THROTTLE
€ 0.00
19
1356347070
ref: 19
PIN,THROTTLE SHAFT
€ 0.00
20
1357345110
ref: 20
ML
SPRING,THROTTLE SHAFT
€ 0.00
21
1355347070
ref: 21
ML
LEVER,THROTTLE SHAFT
€ 0.00
22
1355547070
ref: 22
MR
LEVER ASSEMBLY,THROTTLE
€ 0.00
23
1357347080
ref: 23
MR,RH
SPRING,THROTTLE SHAFT
€ 0.00
24
1362131300
ref: 24
MR
BRACKET,THROTTLE CABLE
€ 14.50
25
1355047090
ref: 25
RH
SHAFT,THROTTLE
€ 0.00
26
1355631210
ref: 26
SEAL
€ 4.00
27
1361744080
ref: 27
LH,RH
E RING
1361744080
€ 3.50
28
1355747070
ref: 28
LH,RH
GASKET,THROTTLE SHAFT (NAS)
1355747070
€ 4.00
29
1360747070
ref: 29
LH,ML,RH
NUT
1360747070
€ 4.00
30
1360547080
ref: 30
LH,ML,RH
SCREW
1360547080
€ 7.00
31
1360573000
ref: 31
MR
SCREW
1360573000
€ 10.50
32
1360444080
ref: 32
SCREW
1360444080
€ 3.50
33
1355147090
ref: 33
VALVE,THROTTLE (BUTTERFLY)
€ 17.00
34
1325144080
ref: 34
GASKET,FLOAT CHAMBER (NAS)
1325144080
€ 9.50
35
1338244030
ref: 35
WASHER
1338244030
€ 3.50
36
1338844030
ref: 36
SPRING
1338844030
€ 6.00
37
0949240014
ref: 37
FROM 09492-40012
JET(40)
0949240014
€ 8.50
38
1335744080
ref: 38
PLUG,NEEDLE JET
1335744080
€ 4.50
39
0949400416
ref: 39
JET, NEEDLE (Y-7)
€ 17.00
40
1333244080
ref: 40
WASHER,NEEDLE NOZZLE
€ 2.50
41
0949124005
ref: 41
JET
0949124005
€ 11.50
42
1324744080
ref: 42
PLUG,DRAIN
1324744080
€ 9.50
43
1324644080
ref: 43
GASKET (NAS)
1324644080
€ 3.50
44
1325044080
ref: 44
FLOAT
1325044080
€ 31.00
45
0211204068
ref: 45
SCREW 4X6
0211204068
€ 2.00
46
1337311400
ref: 46
PLATE,NEEDLE VALVE FITING
1337311400
€ 7.00
47
1325492311
ref: 47
PIN,FLOAT
1325492311
€ 2.00
48
1337011400
ref: 48
VALVE ASSEMBLY,NEEDLE
1337011400
€ 40.50
49
1337444080
ref: 49
O-RING,NEEDLE VALVE
1337444080
€ 6.00
50
1337665010
ref: 50
FILTER
€ 6.50
51
1360234390
ref: 51
LH:4,ML:4,MR:2,RH:4
SCREW
1360234390
€ 2.50
52
1360105188
ref: 52
MR:2
SCREW
€ 2.00
53
1326844010
ref: 53
LH,ML,RH
SPRING,THROTTLE SCREW
1326844010
€ 3.00
54
1357547070
ref: 54
LH,ML,RH
PIN,THROTTLE LEVER
1357547070
€ 2.50
55
0949330005
ref: 55
JET,AIR
0949330005
€ 17.00
56
0211205168
ref: 56
SCREW
0211205168
€ 2.50
57
0832121058
ref: 57
LOCK WASHER
0832121058
€ 2.00
58
1355045410
ref: 58
MR
SHAFT,THROTTLE
€ 0.00
59
1357445110
ref: 59
ML
RING
€ 3.50
60
1357445120
ref: 60
MR
RING
€ 2.50
61
1350234390
ref: 61
COVER
€ 29.00
62
1368231210
ref: 62
CAP,STARTER VALVE
1368231210
€ 5.00
63
1327847090
ref: 63
O RING
1327847090
€ 2.00
64
1321031300
ref: 64
FLANGE ASSEMBLY,CARBURETOR
€ 0.00
65
1342244080
ref: 65
LEVER
1342244080
€ 10.00
66
1360509300
ref: 66
SCREW,THROTTLE ADJUST
1360509300
€ 3.50
67
1341045400
ref: 67
SHAFT,STARTER
€ 0.00
68
0211205128
ref: 68
SCREW
€ 2.50
69
1368345050
ref: 69
L:390->180
HOSE 4.5X8X390
€ 14.00
70
1368531300
ref: 70
NIPPLE,CARBURETOR
1368531300
€ 14.50
71
1368311420
ref: 71
HOSE
€ 13.00
72
0211206128
ref: 72
SCREW 6X12
0211206128
€ 2.00
73
1362744110
ref: 73
BRACKET,THROTTLE ADJUST
€ 12.50
74
0211205108
ref: 74
SCREW
0211205108
€ 2.00
75
0832121058
ref: 75
LOCK WASHER
0832121058
€ 2.00
76
1327137100
ref: 76
SPRING
€ 4.50
77
1343234390
ref: 77
WASHER
€ 1.50
78
1326734390
ref: 78
ADJUSTER
1326734390
€ 15.50
79
1327634390
ref: 79
BUSH
1327634390
€ 6.00
80
1341349220
ref: 80
LEVER,CHOKE CABLE
€ 4.00
81
1342149220
ref: 81
PLATE,CHOKE CABLE
1342149220
€ 3.00
82
1343749220
ref: 82
SPRING,CHOKE CABLE
€ 0.00
83
1368344080
ref: 83
L:250->18
HOSE
€ 26.00
84
1368531310
ref: 84
NIPPLE,CARBURETOR
1368531310
€ 18.00
