SEAT (MODEL N : F.NO. 107282~)

ref

part #

description

quantity

1

4510011301865
ref: 1

SEAT (BLACK)

€ 255.00

2-1

4519111300189
ref: 2-1

MOULDING, RH (WHITE)

€ 16.00

2-2

451911130005K
ref: 2-2

MOULDING, RH (BLUE)

€ 16.00

2-3

451911130005J
ref: 2-3

MOULDING, RH (RED)

€ 16.00

3-1

4519211300189
ref: 3-1

MOULDING, LH (WHITE)

€ 16.00

3-2

451921130005K
ref: 3-2

MOULDING, LH (BLUE)

€ 16.00

3-3

451921130005J
ref: 3-3

MOULDING, LH (RED)

€ 16.00

4

0914806005
ref: 4

NUT

€ 1.50

5

0920006018
ref: 5

PIN

€ 2.00

6

0411120158
ref: 6

PIN

€ 1.50

7

0932108006
ref: 7

CUSHION

€ 3.00

8

0932110001
ref: 8

CUSHION

€ 2.50

9

4521345000
ref: 9

STRIKER,SEAT LOCK

€ 7.50

10

0832221068
ref: 10

WASHER

€ 2.00

11

0832121068
ref: 11

LOCK WASHER

€ 2.50

12

0831921068
ref: 12

NUT 6MM

€ 2.00

13

0916006028
ref: 13

WASHER(6.5X18X1)

€ 1.50

14

9570045813
ref: 14

LOCK ASSY,SEAT

€ 59.50

15

0211205128
ref: 15

SCREW

€ 2.50

16

0832121058
ref: 16

LOCK WASHER

€ 2.00

17

9572245000
ref: 17

SPRING,HELMET HOLDER

€ 8.50

18

0110405088
ref: 18

BOLT 5X16

€ 2.00

19

4551011300189
ref: 19

COVER, SEAT TAIL (WHITE)

€ 65.00

20

681671131070J
ref: 20

TAPE

€ 0.00

21

455101130005J
ref: 21

COVER, SEAT TAIL (RED)

€ 65.00

22

681671131069R
ref: 22

TAPE

€ 0.00

23

455101130005K
ref: 23

COVER, SEAT TAIL (BLUE)

€ 65.00

24

681671131070K
ref: 24

TAPE (BLUE & WHITE)

€ 0.00

25

0916906016
ref: 25

WASHER

€ 1.50

26

0832121068
ref: 26

LOCK WASHER

€ 2.50

27

0831921068
ref: 27

NUT 6MM

€ 2.00

28

4631011300
ref: 28
OPT

CARRIER, SPORTS

€ 51.50

29

4630011850
ref: 29
OPT

BOLT SET, CARRIER

€ 0.00

30

0151708858
ref: 30
OPT

BOLT

€ 3.50

31

0916010041
ref: 31
OPT

WASHER(10.3X25X1.5

€ 4.00

all assemblies
