CHAIN TENSIONER
PE250 1979 (N) USA (E03)
Chain tensioner diagram PE250 1979 (N) USA (E03)
CHAIN TENSIONER PE250 1979 (N) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6135041401
ref: 1
61350-41301
TENSIONER,CHAIN
€ 25.00
2
0110706128
ref: 2
01500-06127
BOLT
€ 2.00
3
0832121068
ref: 3
08321-01067
LOCK WASHER
€ 2.50
4
0916006007
ref: 4
09160-06084
WASHER
€ 2.00
5
0944825002
ref: 5
09448-25003
SPRING
€ 3.00
6
6135241400
ref: 6
61352-41401
PLATE,CHAIN TENSIONER
€ 4.00
7
6134541100
ref: 7
RUBBER,CHAIN GUARD
€ 4.50
8
0831921068
ref: 8
08319-2106A
NUT 6MM
€ 2.00
9
0918006067
ref: 9
SPACER(6.5X10.5X22.5)
€ 2.50
10
0110706358
ref: 10
09100-06033
BOLT
€ 2.50
11
6135041300
ref: 11
61350-41301
TENSIONER,CHAIN
€ 25.00
12
0110706128
ref: 12
01500-06127
BOLT
€ 2.00
13
0832121068
ref: 13
08321-01067
LOCK WASHER
€ 2.50
14
0916006007
ref: 14
09160-06084
WASHER
€ 2.00
15
0944825003
ref: 15
SPRING
€ 3.00
16
6135241300
ref: 16
61352-41301
PLATE,CHAIN TENSIONER
€ 8.00
17
6134541100
ref: 17
RUBBER,CHAIN GUARD
€ 4.50
18
0831921068
ref: 18
08319-2106A
NUT 6MM
€ 2.00
19
0918006067
ref: 19
SPACER(6.5X10.5X22.5)
€ 2.50
20
0110706358
ref: 20
09100-06033
BOLT
€ 2.50
21
6135041301
ref: 21
TENSIONER,CHAIN
€ 25.00
22
0110706128
ref: 22
01500-06127
BOLT
€ 2.00
23
0832121068
ref: 23
08321-01067
LOCK WASHER
€ 2.50
24
0916006007
ref: 24
09160-06084
WASHER
€ 2.00
25
0944825003
ref: 25
SPRING
€ 3.00
26
6135241301
ref: 26
PLATE,CHAIN TENSIONER OUTER
€ 8.00
27
6134541100
ref: 27
RUBBER,CHAIN GUARD
€ 4.50
28
6134541501
ref: 28
ROLLER,CHAIN TENSIONER LWR
€ 6.00
29
0926310007
ref: 29
BEARING(10X14X15)
€ 21.00
30
0831921068
ref: 30
08319-2106A
NUT 6MM
€ 2.00
31
0928410004
ref: 31
SEAL,OIL(10X14.4X3.5)
€ 2.50
32
0918006067
ref: 32
SPACER(6.5X10.5X22.5)
€ 2.50
33
0918006075
ref: 33
SPACER(6.2X10X22.5)
€ 4.00
34
0110706358
ref: 34
09100-06033
BOLT
€ 2.50
35
0832211168
ref: 35
08322-01167
WASHER
€ 2.00
