RADIATOR
RM125 2006 (K6) USA (E03)
Radiator diagram RM125 2006 (K6) USA (E03)
RADIATOR RM125 2006 (K6) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
1771036F00
ref: 1-1
RADIATOR,WATER,R
€ 420.50
1-2
1771036F11
ref: 1-2
RADIATOR,WATER,R
€ 577.00
2
0914806015
ref: 2
NUT
€ 3.50
3
1773012C20
ref: 3
17730-08J00
CAP COMP,RADIATOR
€ 40.00
4
093515080300A
ref: 4
09351-50803-00B
HOSE(5X8X1000)
€ 10.00
5-1
1772036F00
ref: 5-1
RADIATOR,WATER,L
€ 441.00
5-2
1772036F11
ref: 5-2
RADIATOR,WATER,L
€ 620.50
6
0914806015
ref: 6
NUT
€ 3.50
7
1778719A00
ref: 7
CUSHION,RADIATOR LWR
€ 3.50
8
0154706253
ref: 8
01547-0625B
SCREW
€ 2.50
8A
0911606186
ref: 8A
BOLT(6X25)
€ 2.50
9
0916006114
ref: 9
WASHER(6.5X24X1.2)
€ 2.00
10
0918006243
ref: 10
SPACER(6.5X10.5X14.1)
€ 4.50
11
1785136F00
ref: 11
HOSE,RADIATOR INLET
€ 19.00
12
1785236F00
ref: 12
HOSE,RADIATOR OUTLET
€ 15.00
13-1
1785336F00
ref: 13-1
HOSE,RADIATOR JOINT
€ 4.50
13-2
1785336F10
ref: 13-2
HOSE,RADIATOR JOINT NO.1
€ 4.50
13-3
1785337F10
ref: 13-3
17853-36F00
HOSE,RADIATOR
€ 4.50
14
1785329E00
ref: 14
HOSE,RADIATOR JOINT
€ 12.00
15
0940228511
ref: 15
CLAMP
€ 8.50
16
0940222511
ref: 16
CLAMP
€ 6.00
17-1
1776137F00YR1
ref: 17-1
COVER,RADIATOR,R
€ 20.50
17-2
1776137F00YU1
ref: 17-2
17761-37F10-YU1
COVER,RDTR,R
€ 91.50
17-3
1776137F10YU1
ref: 17-3
COVER,RADIATOR,R(YELLOW)
€ 91.50
18-1
1776237F00YR1
ref: 18-1
COVER,RADIATOR,L
€ 20.50
18-2
1776237F00YU1
ref: 18-2
17762-37F10-YU1
COVER,RDTR,L
€ 32.00
18-3
1776237F10YU1
ref: 18-3
COVER,RADIATOR,L(YELLOW)
€ 32.00
19
0916906053
ref: 19
WASHER
€ 2.00
20-1
0916906054
ref: 20-1
09169-06053
WASHER
€ 2.00
20-2
0916906054
ref: 20-2
09169-06053
WASHER
€ 2.00
20-3
6923237F00
ref: 20-3
69232-37F01
WASHER,RR BRAK
€ 7.50
21-1
0154706123
ref: 21-1
01547-0612B
BOLT
€ 2.00
21-2
0910306233
ref: 21-2
BOLT(6X12)
€ 2.00
22-1
1783136E00
ref: 22-1
LOUVER,RADIATOR
€ 12.50
22-2
1783137E11
ref: 22-2
LOUVER,RADIATOR
€ 11.50
23
6866036F00DY9
ref: 23
TAPE, RADIATOR COVER RH
€ 65.50
24
6867036F00DY9
ref: 24
TAPE, RADIATOR COVER LH
€ 65.50
25
6866037F10GY7
ref: 25
TAPE,RADIATOR COVER,R
€ 50.50
26
6867037F10GY7
ref: 26
TAPE,RADIATOR COVER,L
€ 94.00
27
6866037F20KH2
ref: 27
TAPE, RADIATOR COVER RH
€ 119.50
28
6867037F20KH2
ref: 28
TAPE,RADIATOR COVER,L
€ 64.50
29
6866137F00GY8
ref: 29
EMBLEM,SUZUKI
€ 15.50
30
6866037F30NV1
ref: 30
TAPE,RADIATOR COVER,R
€ 61.50
31
6867037F30NV1
ref: 31
TAPE,RADIATOR COVER,L
€ 61.50
32
6866037F40YHB
ref: 32
TAPE,RADIATOR COVER,R
€ 58.00
33
6867037F40YHB
ref: 33
TAPE, RADIATOR COVER LH
€ 95.50
34
6866037F50CET
ref: 34
68660-37F51-CET
TAPE, RADIATOR COVER RH
€ 122.50
35
6867037F50CET
ref: 35
68670-37F51-CET
TAPE, RADIATOR COVER LH
€ 122.50
