WIRING HARNESS

ref

part #

description

quantity

1

3661025D20
ref: 1

HARNESS,WIRING

€ 287.00

2

3661138A00
ref: 2

DIODE(STANLEY DE8804)

€ 13.00

3-1

0940408417
ref: 3-1

CLAMP L:62

€ 3.00

3-2

0940406431
ref: 3-2

CLAMP(L:65)

€ 2.50

3-3

0940408418
ref: 3-3

CLAMP(L:65)

€ 3.50

3-4

0940408419
ref: 3-4

CLAMP(L:80)

€ 2.00

4-1

0940714403
ref: 4-1

CLAMP(L:125)

€ 2.50

4-2

0940718403
ref: 4-2

CLAMP L:165

€ 2.50

4-3

0940725401
ref: 4-3

CLAMP(L:235)

€ 4.00

5-1

3710033E01
ref: 5-1

LOCK ASSY,STEERING

€ 170.00

5-2

3710033E11
ref: 5-2
E24

LOCK ASSY,STEERING

€ 160.00

6

0913908016
ref: 6

BOLT(8X20)

€ 3.50

7

3714646E00
ref: 7
OPT

KEY,BLANK

€ 13.00

8

3674004701
ref: 8

BOX ASSY,FUSE

€ 16.00

9

0948115101
ref: 9

FUSE(15A)

€ 1.50

10

3774031D00
ref: 10

SWITCH ASSY,STOP LAMP

€ 20.50

11

0944306031
ref: 11

SPRING

€ 21.00

12

3784011X50
ref: 12

SWITCH ASSY,SIDE STAND

€ 76.00

13

0155006163
ref: 13

BOLT

€ 2.50

14

3874026E00
ref: 14

RELAY ASSY

€ 32.50

15

3850221E02
ref: 15

HORN ASSY

€ 63.50

16

0155008123
ref: 16

BOLT

€ 3.50
