FRONT FENDER

VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

Front fender diagram VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

FRONT FENDER VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

FRONT FENDER VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

1

5181038A03
ref: 1

HOUSING,HEADLAMP

€ 111.00

2

083193106B
ref: 2

NUT

€ 2.50

3-1

5311038A10YAY
ref: 3-1

FENDER,FR

€ 430.00

3-2

5311038A00YDV
ref: 3-2

FENDER,FR(SILVER)

€ 0.00

3-3

5311038A00YHL
ref: 3-3

FENDER,FR

€ 0.00

3-4

5311038A00YC3
ref: 3-4
53110-38A10-13L

FENDER, FRONT (WHITE)

€ 325.50

3-5

5311038A00YMD
ref: 3-5

FENDER,FR

€ 159.00

3-6

5311038A00YRB
ref: 3-6

FENDER,FR

€ 159.00

4

015700616B
ref: 4

BOLT

€ 2.50
