FUEL COCK

VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

Fuel cock diagram VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

4430038A72
ref: 1

COCK ASSY,FUEL

€ 174.00

4430638A00
ref: 2

LEVER,FUEL COCK

€ 23.50

4430738A00
ref: 3

SCREW,COCK LEVER

€ 18.00

0912806057
ref: 4

BOLT(6X20)

€ 2.00

0916806026
ref: 5

GASKET(6.4X11.5X0.8) (NAS)

€ 3.50

6-1

4432038A02
ref: 6-1
44320-38AR0

HOSE,FUEL PUMP & COCK

€ 11.00

6-2

4432038AA0
ref: 6-2

HOSE,FUEL PUMP & COCK

€ 31.00

4431138A01
ref: 7

TUBE,FUEL HOSE

€ 13.50

0940111415
ref: 8

CLIP

€ 2.50
