HEADLAMP

VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

Headlamp diagram VS800 BOULEVARD S50 2008 (K8) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

3510038A61999
ref: 1

HEADLAMP ASSY

€ 236.00

3512138A60
ref: 2

UNIT,LAMP

€ 114.00

3511138A60
ref: 3

RIM

€ 24.00

3513038A00
ref: 4

RING,MOUNTING

€ 15.00

3517313E10
ref: 5

COVER

€ 12.50

3513638A60
ref: 6

SCREW

€ 3.50

3513638A00
ref: 7

SCREW,MOUNTING

€ 2.50

3513945230
ref: 8

CUSHION

€ 1.50

3515538A60
ref: 9

NUT

€ 3.50

3513938A60
ref: 10

CUSHION

€ 2.50

3515138A00
ref: 11

SCREW,ADJUSTING(4X50)

€ 2.50

3515431300
ref: 12

SPRING

€ 2.00

3515245600
ref: 13

NUT,HEADLAMP ADJUST

€ 3.00

3685338A00
ref: 14

SOCKET

€ 10.00

0940406432
ref: 15

CLAMP(L:65)

€ 2.50

0947112060
ref: 16

BULB(12V60/55W,H4)

€ 8.00

0214205127
ref: 17

SCREW

€ 1.50

3595043431
ref: 18

REFLEX REFLECTOR,FR SIDE

€ 12.00

083100005B
ref: 19
08310-0005A

NUT

€ 2.50

HEADLAMP

all assemblies
