REAR SHOCK ABSORBER

VZ800 MARAUDER 1998 (W) USA (E03)

Rear shock absorber diagram VZ800 MARAUDER 1998 (W) USA (E03)

REAR SHOCK ABSORBER VZ800 MARAUDER 1998 (W) USA (E03)

REAR SHOCK ABSORBER VZ800 MARAUDER 1998 (W) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

6131048E10
ref: 1

CASE,CHAIN

€ 207.50

2

0214206107
ref: 2

SCREW

€ 2.00

3

6210048E10
ref: 3

ABSORBER ASSY,RR SHOCK

€ 384.00

4

0910608094
ref: 4

BOLT(8X20)

€ 8.00

5

6231348E00
ref: 5

BOLT,RR SHOCK ABSORBER

€ 13.50

6

0916008138
ref: 6
09160-08503

WASHER (8.5X30X2.3)

€ 2.00

7

0916010035
ref: 7

WASHER(10.5X28X2.3)

€ 2.00

8

0831310107
ref: 8

NUT

€ 2.50

9

0925006009
ref: 9

CAP(OD:14.5)

€ 3.50
