KICK STARTER

AX100 1996 (T) GENERAL EXPORT (E01) / P9

Kick starter diagram AX100 1996 (T) GENERAL EXPORT (E01) / P9

prices are in EUR

ref

part #

description

quantity

2621123401
ref: 1

SHAFT,KICK STARTER

€ 0.00

2622146000
ref: 2

GUIDE,KICK STARTER SFT SPRING

€ 5.00

2623120000
ref: 3

PAWL,KICK STARTER

€ 13.50

0920905011
ref: 4

PIN(5X15.5)

€ 2.00

0944004010
ref: 5

SPRING

€ 1.50

2623201000
ref: 6

LIFTER,KICK STARTER PAWL

€ 8.00

0212206163
ref: 7

SCREW ,6X16

€ 2.00

2624112010
ref: 8
NT:33

GEAR,KICK STARTER DRIIVE

€ 0.00

0944841003
ref: 9

SPRING

€ 17.00

0916412024
ref: 10
OD:29

WASHER

€ 0.00

0821112302
ref: 11

WASHER

€ 2.50

0916016016
ref: 12

WASHER(16X30X0.5)

€ 2.50

0928516002
ref: 13

SEAL,OIL(16X30X8)

€ 6.50

2623720400
ref: 14

BOLT,KICK START SHAFT SPR HOOK

€ 5.00

2630023400
ref: 15

LEVER ASSY, KICK STARTER

€ 94.50

2635201000
ref: 16

RUBBER,KICK STARTER PEDAL

€ 3.50

0150008253
ref: 17

BOLT

€ 2.50
