prices are in EUR
ref
part #
description
quantity
1
FENDER,REAR
3
BOLT 6X16
4
WASHER
5-2
BODY,REAR FENDER REAR (BLUE)
5-4
BODY,REAR FENDER REAR (WHITE)
5-7
BODY,REAR FENDER REAR (BLUE)
6
CUSHION,RR FENDER
7
CUSHION
8
SPACER (8.2X12X7.5)
9-1
BOLT(8X30)
9-2
BOLT
10
NUT
13-2
NUT
15
CUSHION
16
GUARD,RR UNIT MUD
17
SCREW
18
WASHER(6.5X16X1.2)
20-1
BAG ASSEMBLY,SEAT TAIL
20-2
BAG ASSEMBLY,SEAT TAIL
20-3
BAG SET,SEAT TAIL (BLACK/WHITE)
22
WASHER
24
SPACER (6.1X9X9)
25
LOCK ASSEMBLY,HELMET
26
BOLT 6X11
27
WASHER,LOCK
30
CLAMP(L:125)
31
EXTENSION,RR FENDER
32
BOLT
33
SCREW
34
WASHER
38
BOLT
39
WASHER
40
SCREW
43
BOLT
44
WASHER
45
SCREW
