AIR CLEANER (MODEL Z)

GS1100E 1982 (Z) USA (E03)

Air cleaner (model z) diagram GS1100E 1982 (Z) USA (E03)

AIR CLEANER (MODEL Z) GS1100E 1982 (Z) USA (E03)

AIR CLEANER (MODEL Z) GS1100E 1982 (Z) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1371049500
ref: 1

CASE COMP,AIR CLEANER

€ 0.00

2

1388149020
ref: 2
13881-49021

TUBE,AIR CLEANER OUTLET

€ 16.00

3

1388547030
ref: 3

RING,CARBURETOR AIR INLET HOSE

€ 8.00

4

0940264306
ref: 4
09402-64203

CLAMP

€ 6.00

5

1387000010
ref: 5
13870-11458

DRAIN TUBE

€ 13.50

6

0940114301
ref: 6

CLIP

€ 2.00

7

1385100220
ref: 7
09352-11153-600

TUBE,BREATHER

€ 13.50

8

0940114301
ref: 8

CLIP

€ 2.00

9

1370045810
ref: 9

CLEANER SET,AIR,REAR

€ 176.50

10

1378045500
ref: 10

FILTER,AIR CLEANER

€ 41.00

11

1379549000
ref: 11

HOSE,AIR CLEANER

€ 34.50

12

1379649000
ref: 12

BAND

€ 6.00

13

0211205128
ref: 13
02112-05127

SCREW

€ 2.50

14

0832121058
ref: 14
08321-0105A

LOCK WASHER

€ 2.00

15

0110706208
ref: 15
01500-06207

BOLT

€ 2.00

16

0832121068
ref: 16
08321-01067

LOCK WASHER

€ 2.50

17

0832221068
ref: 17
08322-01067

WASHER

€ 2.00
