FUEL TANK (MODEL Z)

GS1100G 1983 (D) GENERAL EXPORT (E01)

Fuel tank (model z) diagram GS1100G 1983 (D) GENERAL EXPORT (E01)

FUEL TANK (MODEL Z) GS1100G 1983 (D) GENERAL EXPORT (E01)

FUEL TANK (MODEL Z) GS1100G 1983 (D) GENERAL EXPORT (E01)

prices are in EUR

ref

part #

description

quantity

1-1

441104511013L
ref: 1-1

TANK ASSEMBLY,FUEL

€ 324.00

1-2

441104511013L
ref: 1-2

TANK ASSEMBLY,FUEL

€ 324.00

2

6811049410764
ref: 2

TAPE SET,FUEL TANK

€ 0.00

3

6811144600
ref: 3

EMBLEM

€ 0.00

4

0213203065
ref: 4

SCREW 3X6

€ 2.00

5

4420049810
ref: 5

CAP SET,FUEL TANK

€ 121.00

6

0932910016
ref: 6

CUSHION

€ 3.00

7

4454149400
ref: 7

CUSHION,FUEL TANK

€ 9.00

8

0932010020
ref: 8

CUSHION

€ 4.00

9

0932014013
ref: 9

CUSHION

€ 3.00

10

0916006004
ref: 10

WASHER (6.5X24X1.6)

€ 1.50

11

0918006091
ref: 11

SPACER (6.4X9X21.5)

€ 5.50

12

0150006307
ref: 12

BOLT

€ 2.50
