FRONT BRAKE HOSE

GS650GT 1983 (D) (E01 E02 E04 E06)

Front brake hose diagram GS650GT 1983 (D) (E01 E02 E04 E06)

prices are in EUR

ref

part #

description

quantity

5971149001
ref: 1

BOOT,MASTER CYLINDER

€ 8.50

0936010007
ref: 2

BOLT,UNION

€ 6.50

0916110005
ref: 3

WASHER

€ 2.00

4-1

5948034200
ref: 4-1

HOSE,FRONT BRAKE

€ 33.00

4-2

5948045622
ref: 4-2

HOSE,FRONT BRAKE

€ 56.50

5924331010
ref: 5

GUIDE,BRAKE HOSE NO.1

€ 3.00

0930814007
ref: 6

GROMMET

€ 4.00

5949145000
ref: 7

JOINT,BRAKE HOSE

€ 29.00

0110706208
ref: 8

BOLT

€ 2.00

0832121068
ref: 9

LOCK WASHER

€ 2.50

5924034200
ref: 10

HOSE,FRONT BRAKE

€ 52.00

5926834500
ref: 11

CLAMP,FRONT BRAKE HOSE

€ 0.00

5926934500
ref: 12

CLAMP,FRONT BRAKE HOSE

€ 11.00

5924449000
ref: 13

BUSH,BRAKE HOSE GUIDE,NO.2

€ 4.50

0936010007
ref: 14

BOLT,UNION

€ 6.50

0916110005
ref: 15

WASHER

€ 2.00

0936010008
ref: 16

BOLT,UNION

€ 7.00

0916110005
ref: 17

WASHER

€ 2.00
