REAR CALIPERS

GS850GL 1980 (T) USA (E03)

Rear calipers diagram GS850GL 1980 (T) USA (E03)

REAR CALIPERS GS850GL 1980 (T) USA (E03)

REAR CALIPERS GS850GL 1980 (T) USA (E03)

prices are in EUR

ref

part #

description

quantity

0

6910045020
ref: 0
69100-08C00-999

CALIPER ASSEMBLY,REAR

€ 843.50

1

6910045850
ref: 1
69100-08821

PISTON SET

€ 241.00

2

6913045020
ref: 2
69101-45850-XNA

PAD,BRAKE

€ 66.50

3

5910718410
ref: 3
69107-05CF0

SEAL,PISTON

€ 17.00

4

6910845000
ref: 4

BOOT,PISTON

€ 10.00

5

6910745000
ref: 5

SEAL,PISTON

€ 15.50

6

6914545000
ref: 6

BOLT,HOUSING

€ 7.00

7

6914145000
ref: 7

PIN,PAD

€ 6.50

8

6914245000
ref: 8

CLIP,PAD PIN

€ 4.50

9

6914345001
ref: 9

SPRING

€ 8.00

10

6915145000
ref: 10

COVER,DUST

€ 26.50

11

5912118410
ref: 11

BLEEDER

€ 8.00

12

5912218410
ref: 12
55156-66310

CAP,BREATHER

€ 6.00

13

6915245001
ref: 13

SHIM,RR CALIPER

€ 9.50

14

0152710308
ref: 14
01550-10307

BOLT

€ 3.50
