Buy Suzuki GSF Parts Online


FRONT CALIPER (GSF1200SAV)

GSF1200S BANDIT 1997 (V) USA (E03)

Front caliper (gsf1200sav) diagram GSF1200S BANDIT 1997 (V) USA (E03)

FRONT CALIPER (GSF1200SAV) GSF1200S BANDIT 1997 (V) USA (E03)
FRONT CALIPER (GSF1200SAV) GSF1200S BANDIT 1997 (V) USA (E03)
FRONT CALIPER (GSF1200SAV) GSF1200S BANDIT 1997 (V) USA (E03)
prices are in EUR
ref
part #
description
quantity

5910027E50
ref:
CALIPER ASSEMBLY,FRONT,RIGHT
€ 323.00

5930027E50
ref:
CALIPER ASSEMBLY,FRONT,LEFT
€ 501.00
1
5910027820
ref: 1
PISTON SET
€ 179.50
2
5910027830
ref: 2
SEAL SET,PISTON
5910027830
€ 53.00
3
5910027840
ref: 3
PAD SET (NAS)
5910027840
€ 43.00
4
5914533C00
ref: 4
BOLT
5914533C00
€ 9.50
5
5931517C00
ref: 5
SPRING
5931517C00
€ 13.00
6
5934533C00
ref: 6
PIN,HANGER
5934533C00
€ 27.50
7
0411116208
ref: 7
04111-1620A
PIN 16X20
0411116208
€ 2.00
8
5912101A00
ref: 8
BLEEDER
5912101A00
€ 8.50
9
5912201A00
ref: 9
CAP,BLEEDER
5912201A00
€ 4.50
10
0155010303
ref: 10
01550-1030A
BOLT
0155010303
€ 3.00
