TAIL LAMP - LICENSE LAMP
GSXR1100 1987 (H) USA (E03)
Tail lamp - license lamp diagram GSXR1100 1987 (H) USA (E03)
TAIL LAMP - LICENSE LAMP GSXR1100 1987 (H) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3574027A31
ref: 1
LAMP UNIT
€ 13.50
2
3571827A00
ref: 2
35718-20A50
SOCKET & CORD ASSEMBLY
€ 29.00
3-1
0947112084
ref: 3-1
BULB(12V23/8W,TOKAI DENSO)
€ 6.00
3-2
0947112128
ref: 3-2
BULB(12V21/5W,BF141-49642A)
€ 6.00
4
3579627A1023Z
ref: 4
35796-27A10-291
COVER,TAIL LAMP
€ 130.50
4
3579627A1023Z
ref: 4
35796-27A10-291
COVER,TAIL LAMP
€ 130.50
5
6816631300742
ref: 5
68166-31300-13L
EMBLEM
€ 5.00
6
3579627A1013Z
ref: 6
35796-27A10-291
COVER,TAIL LAMP
€ 130.50
7
6816631300742
ref: 7
68166-31300-13L
EMBLEM
€ 5.00
8
3579627A1034R
ref: 8
35796-27A10-291
COVER,TAIL LAMP
€ 130.50
8
3579627A1034R
ref: 8
35796-27A10-291
COVER,TAIL LAMP
€ 130.50
9
6816631300064
ref: 9
EMBLEM(WHITE)
€ 3.50
9A
3579606B1022P
ref: 9A
35796-06B11-22P
COVER,TAIL LAMP
€ 123.00
9B
3579606B1030X
ref: 9B
35796-06B11
COVER,TAIL LAMP
€ 123.00
9C
6865506B0013Z
ref: 9C
68655-06B01-13Z
TAPE,REAR COMBINATION LAMP
€ 6.00
9D
6865506B0022R
ref: 9D
68655-06B01-22R
TAPE,REAR COMBINATION LAMP
€ 8.00
9E
681663130022R
ref: 9E
68166-31300-13L
EMBLEM
€ 5.00
10
3571627A00
ref: 10
PLATE
€ 14.50
11
3572627A00
ref: 11
BRACKET
€ 18.00
12
0831626066
ref: 12
08316-1006B
NUT
€ 2.00
13
0321204169
ref: 13
SCREW
€ 1.50
14
3571640A00
ref: 14
PLATE,TAIL LAMP
€ 5.50
15
0211206166
ref: 15
02112-0616A
SCREW
€ 2.00
16
0831626066
ref: 16
08316-1006B
NUT
€ 2.00
17
0110706206
ref: 17
01500-0620A
BOLT,M6X1X20
€ 2.00
18
0916006020
ref: 18
09160-06066
WASHER
€ 2.00
19
0918006084
ref: 19
09180-06038
SPACER (6.1X9X7.5)
€ 2.00
20
0932009028
ref: 20
CUSHION
€ 3.00
21
3591006B30
ref: 21
35910-28A30
LAMP ASSEMBLY,LICENSE
€ 139.00
22
3591200A10
ref: 22
LENS,LICENSE LAMP
€ 16.00
23
3591304A00
ref: 23
GASKET,LICESE LAMP (NAS)
€ 4.00
24
0211204167
ref: 24
02112-0416A
SCREW
€ 1.00
25
0832121047
ref: 25
08321-0104A
WASHER,LOCK 4M
€ 2.00
26
0832221047
ref: 26
08322-01047
WASHER 4MM
€ 2.00
27
0947112037
ref: 27
09471-12141
BULB
€ 7.00
28
3591706B30
ref: 28
COVER,LICENSE LAMP
€ 35.50
29
0324104165
ref: 29
03242-0416B
SCREW
€ 4.50
30
0916005011
ref: 30
09160-05501
WASHER (5.5X20X1.2)
€ 2.00
31
0831626056
ref: 31
08316-2005A
NUT
€ 2.00
32
3592727A30
ref: 32
BRACKET,LICENSE PLATE
€ 10.00
33
0151706168
ref: 33
01550-06167
BOLT
€ 1.50
34
0916006020
ref: 34
09160-06066
WASHER
€ 2.00
35
0831626066
ref: 35
08316-1006B
NUT
€ 2.00
36
0932106023
ref: 36
CUSHION
€ 2.00
37
3597049310
ref: 37
35970-08A30
REFLECTOR,REFLEX
€ 16.50
38
0916005013
ref: 38
WASHER(5.2X16X1)
€ 1.50
39
0831011058
ref: 39
08310-00057
NUT
€ 2.50
40
3597727A00
ref: 40
SPACER,REAR SIDE,REAR,RIGHT
€ 7.00
41
3597827A00
ref: 41
SPACER,REAR SIDE,REAR,LEFT
€ 4.00
