CRANKSHAFT
RM250 1996 (T) (E02 E04 E24)
Crankshaft diagram RM250 1996 (T) (E02 E04 E24)
CRANKSHAFT RM250 1996 (T) (E02 E04 E24)
×
prices are in EUR
ref
part #
description
quantity
1-1
1211037E000F0
ref: 1-1
MODEL T
PISTON COMP
€ 101.00
1-2
1211037E020F0
ref: 1-2
MODEL V
PISTON
€ 101.00
1-3
1211037E200F0
ref: 1-3
MODEL W
PISTON
€ 75.50
2-1
1214137E00
ref: 2-1
MODEL T
RING,PISTON
€ 33.00
2-2
1214137E01
ref: 2-2
MODEL V/W
RING,PISTON
€ 33.00
3
1215128C00
ref: 3
PIN,PISTON
€ 13.00
4
0938118002A
ref: 4
CIRCLIP,PISTON PIN
€ 1.50
5
0926318016
ref: 5
BEARING(18X23X22)
€ 14.00
6-1
1220037E01
ref: 6-1
MODEL T/V
CRANKSHAFT ASSEMBLY
€ 674.50
6-2
1220037E10
ref: 6-2
MODEL W
CRANKSHAFT ASSEMBLY
€ 466.50
7
1216137E00
ref: 7
CONNECTING ROD
€ 97.50
8
0916024027
ref: 8
WASHER(24X38.5X1.5)
€ 19.50
9
1221105D00
ref: 9
PIN,CRANK
€ 33.00
10
0926324026
ref: 10
BEARING(24X30X20)
€ 62.50
11-1
1222037E01
ref: 11-1
MODEL T/V
CRANKSHAFT,RIGHT
€ 281.00
11-2
1222037E10
ref: 11-2
MODEL W
CRANKSHAFT,R
€ 220.50
12-1
1226037E01
ref: 12-1
MODEL T/V
CRANKSHAFT,LEFT
€ 239.00
12-2
1226037E10
ref: 12-2
MODEL W
CRANKSHAFT,L
€ 285.50
13
0926228027
ref: 13
BEARING(28X68X18)
€ 71.00
14
0928338018
ref: 14
SEAL,OIL(38X52X8)
€ 19.50
15
0928325083
ref: 15
SEAL,OIL(25X37X6)
€ 5.00
16
2111137E01
ref: 16
GEAR,PRIMARY DRIVE (NT:
€ 90.00
17
2114127C11
ref: 17
BOLT,PRIMARY DRIVE GEAR
€ 11.50
18
0916411004
ref: 18
WASHER
€ 6.00
19-1
1210137810
ref: 19-1
OPT, MODEL T
PISTON KIT
€ 125.50
19-2
1210137813
ref: 19-2
OPT, MODEL V
PISTONKIT
€ 125.50
19-3
1210137830
ref: 19-3
OPT, MODEL W
PISTON KIT
€ 136.00
