KICK STARTER

DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

Kick starter diagram DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

prices are in EUR

ref

part #

description

quantity

2621109421
ref: 1

SHAFT,KICK STARTER

€ 34.50

2622109400
ref: 2

GUIDE,KICK STARTER SPRING

€ 2.50

2623109410
ref: 3

STARTER,KICK

€ 16.00

2623209401
ref: 4

GUIDE,KICK STARTER

€ 4.50

2623309400
ref: 5

STOPPER,KICK STARTER

€ 3.00

2624109402
ref: 6

GEAR,KICK STARTER DRIVE(NT:20)

€ 37.00

0918114167
ref: 7

SHIM(14X22X1)

€ 3.50

0928514001
ref: 8

SEAL,OIL(14X24X6)

€ 9.00

0944030007
ref: 9

SPRING

€ 2.00

0944838004
ref: 10

SPRING

€ 5.50

015470612A
ref: 11

BOLT

€ 2.00

0821114321
ref: 12

WASHER

€ 4.00

2630014H00
ref: 13

LEVER ASSY,KICK STARTER

€ 41.50

0944005003
ref: 14

SPRING

€ 1.50

0611107004
ref: 15

BALL

€ 1.50

083313113A
ref: 16

CIRCLIP

€ 1.50

015470620A
ref: 17

BOLT

€ 2.50
