REAR FENDER

DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

Rear fender diagram DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

REAR FENDER DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

REAR FENDER DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

prices are in EUR

ref

part #

description

quantity

1-1

6311114H00019
ref: 1-1

FENDER,RR

€ 40.00

1-2

6311114H00YU1
ref: 1-2

FENDER,RR

€ 53.50

2

6315914H00
ref: 2

CUSHION,RR FENDER

€ 5.00

3

083193106A
ref: 3

NUT

€ 2.50

4

0918006325
ref: 4

SPACER(6.2X8.4X6.9)

€ 3.00

5

035410516A
ref: 5

SCREW

€ 1.50

6-1

6817114H008YM
ref: 6-1

EMBLEM,RR FENDER

€ 10.00

6-2

6817114H00GY8
ref: 6-2

EMBLEM,RR FENDER

€ 10.00
