STAND

DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

Stand diagram DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

STAND DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

STAND DR-Z70 2009 (K9) USA (E03) DRZ70 DR Z70

prices are in EUR

ref

part #

description

quantity

1

4231014H00
ref: 1

STAND,PROP

€ 33.00

2

0911110060
ref: 2

BOLT(10X33)

€ 4.50

3

083193110A
ref: 3

NUT

€ 4.50

4

0944314069
ref: 4

SPRING

€ 9.50

5

4311014H00
ref: 5

PEDAL,BRAKE

€ 49.50

6

0916015002
ref: 6

WASHER(15.5X26X2.3)

€ 3.00

7

041113030A
ref: 7

PIN

€ 2.00

8

0944831017
ref: 8

SPRING

€ 4.00
