STAND (MODEL X)
GS1000 1980 (T) USA (E03)
Stand (model x) diagram GS1000 1980 (T) USA (E03)
STAND (MODEL X) GS1000 1980 (T) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4210045350
ref: 1
STAND,CENTER
€ 80.50
2
0918010040
ref: 2
SPACER(10X16X38.8)
€ 3.00
3
0910110018
ref: 3
09101-10030
BOLT
€ 5.50
4
0832121108
ref: 4
08321-01107
LOCK WASHER
€ 2.00
5
0938510001
ref: 5
09385-10005
CLIP
€ 1.50
6
0944320001
ref: 6
09443-20001-XC0
SPRING
€ 11.00
7
0932110001
ref: 7
CUSHION
€ 2.50
8
4231045000
ref: 8
STAND,PROP
€ 70.00
9
0944317005
ref: 9
09443-17008-XC0
SPRING
€ 11.50
10
0910010067
ref: 10
BOLT(10X30)
€ 3.50
11
0831022106
ref: 11
08310-0010A
NUTM10X1.25X8
€ 2.00
12
0932007001
ref: 12
CUSHION
€ 4.00
13
4233045100
ref: 13
BRACKET,SIDE STAND
€ 22.00
14
0910010007
ref: 14
09100-10287
BOLT
€ 4.50
15
0832121108
ref: 15
08321-01107
LOCK WASHER
€ 2.00
16
4311045350
ref: 16
43110-45351
PEDAL,BRAKE
€ 23.00
17
4312045350
ref: 17
ARM,BRAKE PEDAL ROD
€ 30.50
18
0110708308
ref: 18
01500-08307
BOLT (8X30)
€ 2.50
19
0832121088
ref: 19
08321-01087
LOCK WASHER
€ 2.00
20
0944837017
ref: 20
SPRING
€ 4.00
21
0920006029
ref: 21
PIN
€ 1.50
22
0411120158
ref: 22
04111-2015A
PIN
€ 1.50
23
0832221068
ref: 23
08322-01067
WASHER
€ 2.00
24
0110706208
ref: 24
01500-06207
BOLT
€ 2.00
25
0831011068
ref: 25
08310-00067
NUT
€ 2.50
