HANDLE SWITCH

GSX1300RAZ HAYABUSA 2014 (L4) USA (E03)

Handle switch diagram GSX1300RAZ HAYABUSA 2014 (L4) USA (E03)

HANDLE SWITCH GSX1300RAZ HAYABUSA 2014 (L4) USA (E03)

HANDLE SWITCH GSX1300RAZ HAYABUSA 2014 (L4) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3720015H10
ref: 1

SWITCH ASSY,HANDLE,R

€ 220.00

2

021120530B
ref: 2

SCREW

€ 1.50

3

3740018H12
ref: 3

SWITCH ASSY,HANDLE,L

€ 184.00

4

021120525B
ref: 4

SCREW

€ 1.50

5

021120545B
ref: 5

SCREW

€ 4.00
