BATTERY

GSX650F 2009 (K9) USA (E03)

Battery diagram GSX650F 2009 (K9) USA (E03)

BATTERY GSX650F 2009 (K9) USA (E03)

BATTERY GSX650F 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3361032C10
ref: 1
33610-33E20

BATTERY ASSY(YTX9-BS,12V8AH)

€ 108.50

2

3365216G00
ref: 2

PROTECTOR,BATTERY

€ 5.50

3

0946200046
ref: 3

BAND

€ 4.50

4

3382018H00
ref: 4

WIRE,BATTERY PLUS LEAD

€ 25.00

5

3362427G00
ref: 5

CAP,BATTERY PLUS LEAD

€ 6.50

6

3386017H10
ref: 6

WIRE,BATTERY MINUS LEAD

€ 28.00
