HANDLE LEVER
GSX650F 2009 (K9) USA (E03)
Handle lever diagram GSX650F 2009 (K9) USA (E03)
HANDLE LEVER GSX650F 2009 (K9) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5711029G01
ref: 1
57110-29G01-291
GRIP,THROTTLE
€ 24.00
2
5730044G10
ref: 2
57300-44G11
LEVER ASSY,BRA
€ 49.50
3
5743117H00
ref: 3
57431-17H01
BOLT,PIVOT
€ 6.00
4
083192106A
ref: 4
NUT
€ 2.00
5
5746017C11
ref: 5
57460-14J01
SWITCH ASSY,ST
€ 32.50
6
5746517C00
ref: 6
SCREW
€ 1.50
7
5721122D01
ref: 7
57211-22D01-291
GRIP,LEFT
€ 11.50
8
5750024F20
ref: 8
57500-24F21
LEVER ASSY,CLU
€ 58.50
9
5743117H00
ref: 9
57431-17H01
BOLT,PIVOT
€ 6.00
10
083161006B
ref: 10
NUT
€ 2.50
11
5756002FA0
ref: 11
SWITCH ASSY,CLUTCH
€ 22.00
