STAND

GSX650F 2009 (K9) USA (E03)

Stand diagram GSX650F 2009 (K9) USA (E03)

STAND GSX650F 2009 (K9) USA (E03)

STAND GSX650F 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4231017H00
ref: 1

STAND,PROP

€ 147.50

2

0944312048
ref: 2

SPRING

€ 22.00

3

0944319010
ref: 3

SPRING

€ 6.00

4

0911110065
ref: 4

BOLT(10X38)

€ 6.50

5

4232103FK0
ref: 5

NUT,PROP STAND

€ 4.50

6

4311138G00
ref: 6

PEDAL,BRAKE

€ 91.00

7

0916018022
ref: 7

WASHER(18X24X1)

€ 3.00

8

4356032C00
ref: 8

BRACKET,STOP LAMP SWITCH SPR

€ 3.00

9

021120516B
ref: 9

SCREW

€ 2.00

10

0944313029
ref: 10

SPRING

€ 5.00

11

4326117C00
ref: 11

TUBE,BRAKE SPRING GUIDE

€ 5.50
