CRANKCASE COVER
GSXR1000 2001 (K1) USA (E03)
Crankcase cover diagram GSXR1000 2001 (K1) USA (E03)
CRANKCASE COVER GSXR1000 2001 (K1) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1134040F00
ref: 1
COVER,CLUTCH
€ 247.00
2
1197133210
ref: 2
LENS,OIL LEVEL CHECK
€ 13.50
3
1148240F00
ref: 3
GASKET,CL COVE (NAS)
€ 15.50
4
0421109189
ref: 4
PIN
€ 2.00
5
0916806023
ref: 5
GASKET(5.8X13X1.2) (NAS)
€ 2.00
6
0712006303
ref: 6
07120-0630B
BOLT
€ 3.00
7
0712006303
ref: 7
07120-0630B
BOLT
€ 3.00
8
1197112C51
ref: 8
PLUG,OIL FILLER
€ 7.00
9
0928017003
ref: 9
O RING(D:3.1,ID:16.8)
€ 2.00
10
1138135F00
ref: 10
11381-35F01
COVER,STARTER CLUTCH
€ 201.00
11
1149133E02
ref: 11
GASKET,STARTER CLUTCH COVER
€ 8.00
12
0421109149
ref: 12
PIN
€ 2.00
13
0712006253
ref: 13
07120-0625A
BOLT,OIL PAN
€ 2.50
14
0712006353
ref: 14
07120-0635B
BOLT
€ 3.50
15
0916806023
ref: 15
GASKET(5.8X13X1.2) (NAS)
€ 2.00
16-1
092593601620H
ref: 16-1
PLUG(SILVER)
€ 10.50
16-2
0925936021
ref: 16-2
PLUG
€ 11.00
17
0928033004
ref: 17
O RING(D:3.1,ID:32.7)
€ 2.50
18
1138233E00
ref: 18
CAP,STARTER IDLE GEAR
€ 66.50
19
1149233E00
ref: 19
GASKET,START IDLE GEAR CAP (NAS)
€ 6.50
20
0712006553
ref: 20
07120-0655B
BOLT
€ 3.00
21
0916806023
ref: 21
GASKET(5.8X13X1.2) (NAS)
€ 2.00
22
0421109149
ref: 22
PIN
€ 2.00
23
0712006253
ref: 23
07120-0625A
BOLT,OIL PAN
€ 2.50
24
0712006353
ref: 24
07120-0635B
BOLT
€ 3.50
25
1135135F02
ref: 25
COVER,MAGNETO
€ 172.00
26
1148335F00
ref: 26
GASKET,MAGNETO COVER (NAS)
€ 11.50
27
0421109149
ref: 27
PIN
€ 2.00
28
0712006303
ref: 28
07120-0630B
BOLT
€ 3.00
29
0712006453
ref: 29
07120-0645B
06453
€ 3.50
30
0916806023
ref: 30
GASKET(5.8X13X1.2) (NAS)
€ 2.00
31
1136140F00
ref: 31
11361-40F01
COVER,ENG SPRO
€ 160.50
32
0421109129
ref: 32
PIN
€ 2.00
33
0712006553
ref: 33
07120-0655B
BOLT
€ 3.00
34
0712006903
ref: 34
07120-0690B
BOLT
€ 3.50
35
0925030003
ref: 35
CAP(OD:36)
€ 4.00
