CARBURETOR

RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)

Carburetor diagram RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)

CARBURETOR RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
CARBURETOR RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
CARBURETOR RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
prices are in EUR
ref
part #
description
quantity
1
1320140A01
ref: 1
CARBURETOR ASSY,L
€ 0.00
1
1320140A11
ref: 1
E2,E4,E15,E16,E21,E2
CARBURETOR ASSY, LH
€ 0.00
2
1320240A01
ref: 2
CARBURETOR ASSY, RH
€ 0.00
2
1320240A11
ref: 2
E2,E4,E15,E16,E21,E2
CARBURETOR ASSY, RH
€ 0.00
3
1362916700
ref: 3
RING
1362916700
€ 11.50
4
1339410010
ref: 4
CLIP
1339410010
€ 4.50
5
0949400471
ref: 5
JET,NEEDLE(P-0)
0949400471
€ 27.00
5
0949400527
ref: 5
E2,E4,E15,E16,E21,E2
JET, NEEDLE (P-O)
€ 27.00
6
1338340A00
ref: 6
NEEDLE,JET
1338340A00
€ 14.00
6
1338340A00
ref: 6
E2,E4,E15,E16,E21,E2
NEEDLE,JET
1338340A00
€ 14.00
7
1326916700
ref: 7
1 3/4
SCREW,AIR
1326916700
€ 9.50
8
1326801010
ref: 8
SPRING
1326801010
€ 3.50
9
1368440A00
ref: 9
HOSE(3X5X650)
1368440A00
€ 7.50
10
1333244080
ref: 10
WASHER,NEEDLE NOZZLE
€ 2.50
11
1366116600
ref: 11
NUT
1366116600
€ 5.00
12
1357741612
ref: 12
ADJUSTER,CABLE
1357741612
€ 8.00
13
1326116700
ref: 13
CAP,CARBURETOR TOP
1326116700
€ 14.50
14
1326616700
ref: 14
GASKET,CARBURETOR TOP (NAS)
€ 6.00
15
1326835010
ref: 15
SPRING
1326835010
€ 3.00
16
1326716700
ref: 16
ADJUSTER,THROTTLE STOP
1326716700
€ 11.00
17
1329533010
ref: 17
O RING
1329533010
€ 4.50
18
1325229630
ref: 18
FLOAT
1325229630
€ 22.50
19
1325129630
ref: 19
LH
GASKET,FLOAT CHAMBER (NAS)
1325129630
€ 7.00
20
1325116700
ref: 20
RH
GASKET, FLOAT CHAMBER
€ 7.00
21
0949132002
ref: 21
JET,MAIN(160)
0949132002
€ 6.50
22
0949220008
ref: 22
FROM 09492-20002
JET,PILOT 20
0949220008
€ 10.00
23
1325492311
ref: 23
PIN,FLOAT
1325492311
€ 2.00
24
1337046900
ref: 24
VALVE ASSY,NEEDLE
1337046900
€ 54.50
25
1337339110
ref: 25
PLATE
1337339110
€ 6.50
26
0211204086
ref: 26
SCREW
€ 2.00
27
0211204167
ref: 27
SCREW
0211204167
€ 1.00
28
0832121047
ref: 28
WASHER,LOCK 4M
0832121047
€ 2.00
29
1368337420
ref: 29
L:510->130
HOSE
€ 5.50
30
1369336500
ref: 30
PLATE,CARBURETOR
1369336500
€ 3.50
31
1368133010
ref: 31
CAP,CABLE ADJUSTER
1368133010
€ 8.00
32
0211204126
ref: 32
SCREW
€ 1.50
33
0832121046
ref: 33
LOCK WASHER
0832121046
€ 2.00
34
1357316700
ref: 34
SPRING
1357316700
€ 6.00
35
1355116700
ref: 35
VALVE, THROTTLE (CA:2.0)
€ 0.00
36
1339816700
ref: 36
JOINT
1339816700
€ 7.00
37
1360103108
ref: 37
SCREW
€ 1.50
38
1329135010
ref: 38
WASHER
1329135010
€ 2.50
39
1324702340
ref: 39
PLUG,DRAIN
1324702340
€ 5.50
40
1368316700
ref: 40
HOSE
1368316700
€ 21.00
41
1368316700
ref: 41
HOSE
1368316700
€ 21.00
42
1367133110
ref: 42
CLIP
€ 3.00
43
0940406404
ref: 43
CLAMP
0940406404
€ 3.00
