CRANKCASE

RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)

Crankcase diagram RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)

CRANKCASE RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
CRANKCASE RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
CRANKCASE RG250FC 1987 (H) (E01 E02 E06 E15 E16 E22 E24 E25 E30 E34)
prices are in EUR
ref
part #
description
quantity
1
1130140810
ref: 1
CRANKCASE SET
€ 627.00
2
0920613001
ref: 2
PIN
0920613001
€ 2.50
3
0151706605
ref: 3
BOLT ,6X60
€ 2.50
4
0151706705
ref: 4
BOLT
€ 2.50
5
0151706905
ref: 5
BOLT (6X90)
€ 3.50
6
0151708405
ref: 6
BOLT 8X40
€ 3.50
7
0151708555
ref: 7
BOLT
€ 3.00
8
0151708605
ref: 8
BOLT 8X60
€ 3.50
9
0916808008
ref: 9
GASKET 8.2X14X1 (NAS)
0916808008
€ 1.00
10
0151708705
ref: 10
BOLT (8X70)
€ 2.50
11
0151708755
ref: 11
BOLT
€ 3.50
12
0151708855
ref: 12
BOLT 8X85
€ 3.50
13
0910010213
ref: 13
BOLT (10X225)
€ 9.50
14
0910010209
ref: 14
BOLT (10X140)
€ 4.00
15
0931910042
ref: 15
BUSH
0931910042
€ 16.50
16
1161017600
ref: 16
SPACER,ENGINE MOUNT
€ 9.00
17
1161116700
ref: 17
PLATE, ENGINE MOUNT
€ 0.00
18
1161216700
ref: 18
SPACER, ENGINE MOUNT (L:11)
€ 0.00
19
0918010087
ref: 19
SPACER(10.2X16X40)
0918010087
€ 4.50
20
0918010088
ref: 20
SPACER
€ 8.00
21
0915910042
ref: 21
NUT
0915910042
€ 3.50
22
0916010066
ref: 22
WASHER (10.5X24X2.3)
0916010066
€ 2.00
23
0831931105
ref: 23
NUT 10MM
€ 3.00
24
0151708655
ref: 24
BOLT (8X65)
€ 3.00
25
0931908023
ref: 25
BUSHING
€ 11.50
26
0831931085
ref: 26
NUT
€ 2.50
27
0924714025
ref: 27
PLUG
0924714025
€ 3.50
28
0916814004
ref: 28
GASKET(14X19.2X2) (NAS)
0916814004
€ 2.50
