CRANKCASE COVER

VL800Z BOULEVARD C50 2005 (K5) CALIFORNIA (E33)

Crankcase cover diagram VL800Z BOULEVARD C50 2005 (K5) CALIFORNIA (E33)

CRANKCASE COVER VL800Z BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
CRANKCASE COVER VL800Z BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
CRANKCASE COVER VL800Z BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1
1134041F00
ref: 1
COVER,CLUTCH
€ 281.00
2
1197133210
ref: 2
LENS,OIL LEVEL CHECK
1197133210
€ 13.50
3
1148241F00
ref: 3
GASKET,CLUTCH COVER (NAS)
1148241F00
€ 15.50
4-1
0910306228
ref: 4-1
BOLT(6X105)
0910306228
€ 4.00
4-2
0910306270
ref: 4-2
BOLT(6X105)
€ 2.50
5
0916806023
ref: 5
GASKET(5.8X13X1.2) (NAS)
0916806023
€ 2.00
6-1
0925920007
ref: 6-1
PLUG(20X10)
0925920007
€ 6.50
6-2
1197125D00
ref: 6-2
PLUG,ENGINE OIL FILLER
1197125D00
€ 5.50
7
0928017003
ref: 7
O RING(D:3.1,ID:16.8)
0928017003
€ 2.00
8-1
0154706307
ref: 8-1
BOLT
0154706307
€ 2.50
8-2
0910306213
ref: 8-2
BOLT(6X30)
0910306213
€ 2.50
9-1
0154706507
ref: 9-1
BOLT
0154706507
€ 2.50
9-2
0910306238
ref: 9-2
BOLT(6X50)
0910306238
€ 2.50
10-1
0154706857
ref: 10-1
BOLT
0154706857
€ 2.50
10-2
0910306226
ref: 10-2
BOLT(6X85)
0910306226
€ 2.50
11
0421109189
ref: 11
PIN
0421109189
€ 2.00
12
1135141F00
ref: 12
11351-41F10
COVER GENERATO
€ 315.50
13
1148341F00
ref: 13
GASKET,GENERATOR COVER (NAS)
1148341F00
€ 11.50
14
0916806023
ref: 14
GASKET(5.8X13X1.2) (NAS)
0916806023
€ 2.00
15
0920611007
ref: 15
PIN(8.4X11X20)
0920611007
€ 1.50
16-1
0154706407
ref: 16-1
BOLT
0154706407
€ 2.50
16-2
0910306215
ref: 16-2
BOLT(6X40)
0910306215
€ 2.00
17-1
0154706557
ref: 17-1
BOLT
0154706557
€ 2.50
17-2
0910306216
ref: 17-2
BOLT(6X55)
0910306216
€ 2.50
18-1
0154706857
ref: 18-1
BOLT
0154706857
€ 2.50
18-2
0910306226
ref: 18-2
BOLT(6X85)
0910306226
€ 2.50
19
0421109189
ref: 19
PIN
0421109189
€ 2.00
20
0925936008
ref: 20
Chrome Crankshaft Plug
0925936008
€ 8.50
21
0928033004
ref: 21
O RING(D:3.1,ID:32.7)
0928033004
€ 2.50
22
0924814005
ref: 22
PLUG,14X12
0924814005
€ 5.00
23
0916814002
ref: 23
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
0916814002
€ 2.50
24-1
0925008014
ref: 24-1
CAP(OD:12)
0925008014
€ 3.50
24-2
0925008012
ref: 24-2
CAP(OD:12)
0925008012
€ 2.00
25
1136141F00
ref: 25
COVER,SECONDARY DRIVE UNIT
1136141F00
€ 163.50
26
0916006125
ref: 26
WASHER(6.5X14X1.6)
0916006125
€ 2.00
27
0916109005
ref: 27
WASHER(8.7X16X5)
0916109005
€ 2.50
28
0918006280
ref: 28
SPACER(6.5X9X41.3)
0918006280
€ 4.00
29-1
0154706557
ref: 29-1
BOLT
0154706557
€ 2.50
29-2
0910306216
ref: 29-2
BOLT(6X55)
0910306216
€ 2.50
