FRONT CALIPER

XF650 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

Front caliper diagram XF650 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

FRONT CALIPER XF650 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

FRONT CALIPER XF650 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

prices are in EUR

ref

part #

description

quantity

0

5910033D40
ref: 0

CALIPER,FRONT,

€ 552.00

1

5930033830
ref: 1

PISTON SET

€ 65.50

2

5930033840
ref: 2

SEAL SET,PISTON

€ 26.50

3

5910033880
ref: 3

PAD SET (NAS)

€ 57.00

4

5911533D00
ref: 4

SPRING,PAD,R

€ 12.00

5

5911244B00
ref: 5

BOOT,AXLE

€ 8.00

6

5931336500
ref: 6

INSULATOR,AXLE

€ 5.50

7

5911633D00
ref: 7

GUIDE,PAD

€ 6.50

8

5912118410
ref: 8

BLEEDER

€ 8.00

9

5515666310
ref: 9

CAP,BLEEDER PLUG

€ 6.00

10

5914144B01
ref: 10

PIN,PAD

€ 8.00

11

6914245000
ref: 11

CLIP,PAD PIN

€ 4.50

12

0155010253
ref: 12

BOLT

€ 3.00
