SECONDARY DRIVE GEAR

ref

part #

description

quantity

0

2490045830
ref: 0

SHIM SET,SECONDARY DRIVE

€ 248.00

1

2490045811
ref: 1
NT:16/17

GEAR SET,SECON

€ 352.00

2

0926532001
ref: 2

BEARING(32X58X17)

€ 46.00

3-1

0918132001
ref: 3-1

SHIM (32X38X1.6)

€ 4.50

3-2

0918132002
ref: 3-2

SHIM(32X38X1.62)

€ 4.00

3-3

0918132003
ref: 3-3

SHIM (32X38X1.64)

€ 3.00

3-4

0918132004
ref: 3-4

SHIM (32X38X1.66)

€ 3.50

3-5

0918132005
ref: 3-5

SHIM (32X38X1.68)

€ 3.00

3-6

0918132006
ref: 3-6

SHIM (32X38X1.7)

€ 4.00

3-7

0918132007
ref: 3-7

SHIM (32X38X1.8)

€ 3.00

3-8

0918132008
ref: 3-8

SHIM (32X38X1.9)

€ 4.00

3-9

0918132009
ref: 3-9

SHIM(32X38X2)

€ 4.50

4

0915932001
ref: 4

NUT

€ 9.50

5

2493145100
ref: 5

HOUSING,SECONDARY DRIVE

€ 58.00

6

0926525012
ref: 6

TAPER,ROLLER BEARING

€ 52.50

7

0926525011
ref: 7

BEARING

€ 44.00

8

0918025056
ref: 8

SPACER (25.2X30X40)

€ 7.00

9-1

0918125006
ref: 9-1

SHIM (25X30X1.6)

€ 3.00

9-2

0918125007
ref: 9-2

SHIM (25X30X1.62)

€ 3.00

9-3

0918125008
ref: 9-3

SHIM (25X30X1.64)

€ 3.00

9-4

0918125009
ref: 9-4

SHIM (25X30X1.66)

€ 3.00

9-5

0918125010
ref: 9-5

SHIM (25X30X1.68)

€ 3.00

9-6

0918125011
ref: 9-6

SHIM (25X30X1.7)

€ 3.00

9-7

0918125012
ref: 9-7

SHIM (25X30X1.8)

€ 3.00

9-8

0918125013
ref: 9-8

SHIM (25X30X1.9)

€ 3.00

9-9

0918125014
ref: 9-9

SHIM (25X30X2

€ 3.00

10

2495149100
ref: 10

FLANGE,UNIVERSAL JOINT

€ 68.00

11

0916014021
ref: 11

WASHER(14X29X4)

€ 5.00

12

0915914010
ref: 12

NUT

€ 11.00

13

2494145101
ref: 13

HOUSING,SECONDARY DRIVE

€ 76.50

14

0928335018
ref: 14

SEAL,OIL(35X52X9)

€ 13.00

15

0928070005
ref: 15

O RING(D:3.1,ID:69.4)

€ 6.50

16-1

2494545101
ref: 16-1

SHIM,DRIVEN GEAR HOUSING

€ 4.00

16-2

2494545100
ref: 16-2

SHIM,DRIVEN GEAR HOUSING

€ 4.00

16-3

2494545102
ref: 16-3

SHIM,DRIVEN GEAR HOUSING

€ 4.50

16-4

2494545103
ref: 16-4

SHIM,DRIVEN GEAR HOUSING

€ 4.50

16-5

2494545104
ref: 16-5

SHIM,DRIVEN GEAR HOUSING

€ 4.00

17

0928063004
ref: 17

O RING(D:2.4,ID:62.6)

€ 9.50

18

0151708208
ref: 18

BOLT

€ 3.00

19-1

2493545101
ref: 19-1

SHIM,SECONDARY DRIVE

€ 5.00

19-2

2493545100
ref: 19-2

SHIM,SECONDARY DRIVE

€ 13.00

19-3

2493545102
ref: 19-3

SHIM,SECONDARY DRIVE

€ 13.00

19-4

2493545103
ref: 19-4

SHIM,DRIVE GEAR HOUSING

€ 5.50

19-5

2493545104
ref: 19-5

SHIM,SECONDARY DRIVE

€ 4.50

20

0151708258
ref: 20

BOLT

€ 2.50

21

0924158001
ref: 21

PLUG

€ 15.00
