FRONT BRAKE HOSE

GSX1100EF 1984 (E) (01 02 04 06 15 16 17 18 21 22 24 25 26 34 39

Front brake hose diagram GSX1100EF 1984 (E) (01 02 04 06 15 16 17 18 21 22 24 25 26 34 39

FRONT BRAKE HOSE GSX1100EF 1984 (E) (01 02 04 06 15 16 17 18 21 22 24 25 26 34 39
FRONT BRAKE HOSE GSX1100EF 1984 (E) (01 02 04 06 15 16 17 18 21 22 24 25 26 34 39
FRONT BRAKE HOSE GSX1100EF 1984 (E) (01 02 04 06 15 16 17 18 21 22 24 25 26 34 39
prices are in EUR
ref
part #
description
quantity
1-1
5971149001
ref: 1-1
GSX1100EE/EF/EG
BOOT,MASTER CYLINDER
5971149001
€ 8.50
1-2
5971104700
ref: 1-2
GSX1100ESE/EFE/ESF/E
BOOT,MASTER CYLINDER
5971104700
€ 14.50
2
0936010017
ref: 2
BOLT UNION
0936010017
€ 6.50
3
0916110009
ref: 3
WASHER(10X15X1.5)
0916110009
€ 2.00
4-1
5948000A02
ref: 4-1
GSX1100EE/EF
HOSE,FRONT BRAKE
€ 46.00
4-2
5948000A11
ref: 4-2
GSX1100EE/EF/EG
HOSE, BRAKE NO.1 (L:380) FLAT
€ 46.00
4-3
5948000A22
ref: 4-3
GSX1100ESE/EFE/ESF/E
HOSE,FRONT BRAKE
5948000A22
€ 56.50
5
5949000A00
ref: 5
JOINT,BRAKE HOSE
€ 0.00
6
0110706205
ref: 6
BOLT
0110706205
€ 2.00
7
0832121064
ref: 7
WASHER,LOCK
0832121064
€ 2.00
8
5929043500
ref: 8
ADAPTER,BRAKE HOSE
5929043500
€ 34.50
9
5924000A02
ref: 9
HOSE,FRONT BRAKE NO.2
5924000A02
€ 54.50
