OIL PUMP - OIL FILTER

GSX1100ES 1983 (D) UNITED KINGDOM GERMANY (E02 E22)

Oil pump - oil filter diagram GSX1100ES 1983 (D) UNITED KINGDOM GERMANY (E02 E22)

OIL PUMP - OIL FILTER GSX1100ES 1983 (D) UNITED KINGDOM GERMANY (E02 E22)
OIL PUMP - OIL FILTER GSX1100ES 1983 (D) UNITED KINGDOM GERMANY (E02 E22)
OIL PUMP - OIL FILTER GSX1100ES 1983 (D) UNITED KINGDOM GERMANY (E02 E22)
prices are in EUR
ref
part #
description
quantity
1-1
1151149200
ref: 1-1
MODEL Z
PAN,OIL
€ 255.50
1-2
1151149220
ref: 1-2
MODEL D
PAN,OIL
€ 255.50
2
1148949200
ref: 2
GASKET,OIL PAN (MCA)
1148949200
€ 13.00
3
0928013001
ref: 3
O RING(D:3.2,ID:12.9)
0928013001
€ 4.00
4-1
0151706258
ref: 4-1
MODEL Z
BOLT
0151706258
€ 2.50
4-2
0151706255
ref: 4-2
MODEL D
BOLT
€ 2.50
5
0924714001
ref: 5
PLUG
0924714001
€ 5.00
6
0916814004
ref: 6
GASKET(14X19.2X2) (NAS)
0916814004
€ 2.50
7
1651045040
ref: 7
FILTER ASSY,ENGINE OIL
1651045040
€ 7.50
8
1651849200
ref: 8
O RING,OIL FILTER CHAMBER CAP
1651849200
€ 8.50
9
0944032004
ref: 9
SPRING
0944032004
€ 13.50
10-1
1653149210
ref: 10-1
MODEL Z
CAP,ENG OIL FLTR OUTER CHAMBER
1653149210
€ 41.00
10-2
1653149220
ref: 10-2
MODEL D
CAP,ENGINE OIL FILTER
€ 35.50
11
0142106258
ref: 11
STUD 6X25
0142106258
€ 2.50
12-1
0831311068
ref: 12-1
MODEL Z
NUT
0831311068
€ 2.00
12-2
0831311065
ref: 12-2
MODEL D
NUT 6MM
0831311065
€ 2.00
13-1
0832221068
ref: 13-1
MODEL Z
WASHER
0832221068
€ 2.00
13-1
0832221065
ref: 13-1
MODEL D
WASHER
€ 2.00
14
1640049220
ref: 14
PUMP ASSY,ENGINE OIL
1640049220
€ 155.00
15
1649149200
ref: 15
O-RING,OIL PUMP
1649149200
€ 12.50
16
0910306045
ref: 16
BOLT(6X32)
0910306045
€ 3.00
17
1633149000
ref: 17
GEAR,ENG OIL PUMP DRIVEN(NT:33
1633149000
€ 84.50
18
0822110185
ref: 18
SHIM
0822110185
€ 2.00
19
0926104009
ref: 19
PIN(4X15.8)
0926104009
€ 1.50
20
0833131109
ref: 20
CIRCLIP
0833131109
€ 2.00
21
1652049200
ref: 21
STRAINER,ENGINE OIL
1652049200
€ 58.50
22
0211206128
ref: 22
SCREW 6X12
0211206128
€ 2.00
