TURN SIGNAL LAMP (E1,E6,E24)

GSXR750 1986 (G) (E01 E02 E04 E15 16 17 18 21 22 24 25 34 39 53)

Turn signal lamp (e1,e6,e24) diagram GSXR750 1986 (G) (E01 E02 E04 E15 16 17 18 21 22 24 25 34 39 53)

TURN SIGNAL LAMP (E1,E6,E24) GSXR750 1986 (G) (E01 E02 E04 E15 16 17 18 21 22 24 25 34 39 53)
TURN SIGNAL LAMP (E1,E6,E24) GSXR750 1986 (G) (E01 E02 E04 E15 16 17 18 21 22 24 25 34 39 53)
TURN SIGNAL LAMP (E1,E6,E24) GSXR750 1986 (G) (E01 E02 E04 E15 16 17 18 21 22 24 25 34 39 53)
prices are in EUR
ref
part #
description
quantity
1-1
3560127A02
ref: 1-1
MODEL F TO 35601-27A
LAMP ASSY,REAR TURN SIGNAL
€ 88.50
1-2
3560106B00
ref: 1-2
MODEL G/H
LAMP ASSY, FRONT TURN SIGNAL
3560106B00
€ 88.50
2
3561227A00
ref: 2
LENS
€ 11.50
3
3561327A00
ref: 3
GASKET (NAS)
3561327A00
€ 3.00
4
3562327A00
ref: 4
SCREW(3X30)
3562327A00
€ 1.50
5
3572540511
ref: 5
SCREW
3572540511
€ 1.50
6
3562727A02
ref: 6
GASKET (NAS)
3562727A02
€ 1.50
7
0947112006
ref: 7
BULB(12V23W,STANLEY,A4577A)
0947112006
€ 4.00
8
3567427A00
ref: 8
GROMMET
3567427A00
€ 13.50
9
0831626105
ref: 9
NUT
0831626105
€ 3.50
10-1
3560127A02
ref: 10-1
MODEL F TO 35601-27A
LAMP ASSY,REAR TURN SIGNAL
€ 88.50
10-2
3560306B10
ref: 10-2
MODEL G/H
LAMP ASSY,REAR TURN SIGNAL
€ 88.50
11
3561227A00
ref: 11
LENS
€ 11.50
12
3561327A00
ref: 12
GASKET (NAS)
3561327A00
€ 3.00
13
3562327A00
ref: 13
SCREW(3X30)
3562327A00
€ 1.50
14
3572540511
ref: 14
SCREW
3572540511
€ 1.50
15
3562727A02
ref: 15
GASKET (NAS)
3562727A02
€ 1.50
16
0947112006
ref: 16
BULB(12V23W,STANLEY,A4577A)
0947112006
€ 4.00
17
3569506B00
ref: 17
MODEL G/H
SPACER
3569506B00
€ 4.50
18
3569206B00
ref: 18
MODEL G/H
CUSHION
3569206B00
€ 4.50
19
0916010078
ref: 19
MODEL G/H
WASHER (10.2X27X1.6)
0916010078
€ 2.00
20
0831626105
ref: 20
NUT
0831626105
€ 3.50
21
3861031310
ref: 21
RELAY ASSEMBLY,TURN SIGNAL
€ 54.50
