REAR WHEEL
RM125 2000 (Y)
Rear wheel diagram RM125 2000 (Y)
REAR WHEEL RM125 2000 (Y)
×
prices are in EUR
ref
part #
description
quantity
1
6411143D00
ref: 1
HUB,RR WHEEL
€ 285.00
2
6473143D00
ref: 2
SPACER,RR HUB BEARING
€ 47.50
3
0813360047
ref: 3
BEARING
€ 21.00
4
0833141426
ref: 4
CIRCLIP
€ 1.50
5
6484128E00
ref: 5
SEAL(29X42X6)
€ 8.50
6
6921143D00
ref: 6
<-69211-43D10
DISC,RR BRAKE
€ 160.00
7
0912006011
ref: 7
SCREW
€ 2.50
8
6471128E00
ref: 8
AXLE,RR
€ 62.50
9
6475128E20
ref: 9
SPACER,RR AXLE
€ 13.00
10
6475128E20
ref: 10
SPACER,RR AXLE
€ 13.00
11
0916019022
ref: 11
WASHER(19X32X3.2)
€ 5.00
12
0831440183
ref: 12
NUT
€ 4.50
13
0411140308
ref: 13
PIN,COTTER
€ 1.50
14-1
6451128E00
ref: 14-1
MODEL T
SPROCKET,RR(NT:49)
€ 99.00
14-2
6451136E00
ref: 14-2
MODEL V/W
SPROCKET,RR(NT:50)
€ 99.00
14-3
6451114D60
ref: 14-3
OPT ALUMINIUM
SPROCKET,RR(NT:48)
€ 195.00
14-4
6451140261
ref: 14-4
OPT ALUMINIUM
SPROCKET,RR(NT:51 AL)
€ 87.50
15
0912008010
ref: 15
BOLT(8X30.5)
€ 2.50
16
0915908067
ref: 16
NUT
€ 5.50
17
6531127C10
ref: 17
RIM,REAR WHEEL (1.85X19)(A
€ 357.00
18
6532028C10
ref: 18
SPOKE SET,RR WHEEL
€ 97.00
19-1
6511043D10
ref: 19-1
MODEL T/V
TIRE,REAR 100/90-19
€ 154.50
19-2
6511036E00
ref: 19-2
MODEL W
TIRE,REAR 100/90-19
€ 154.50
20
5520044610
ref: 20
TUBE
€ 41.00
21
6526101B30
ref: 21
PROTECTOR,WHL INR TUBE
€ 3.50
22
6527043D00
ref: 22
STOPPER,BEAD(1.85)
€ 30.50
23
6527127C00
ref: 23
CUSHION,BEAD STOPPER
€ 5.50
24
0832201083
ref: 24
WASHER
€ 1.50
25
0831000083
ref: 25
NUT
€ 1.50
26
6920028C00
ref: 26
COVER SET,RR BRAKE DISC
€ 29.50
27
0155006203
ref: 27
BOLT
€ 2.50
28
0155006123
ref: 28
BOLT
€ 2.50
