SEAT
RMX50 1996 (T) PORTUGAL SPAIN (E29 E53)
Seat diagram RMX50 1996 (T) PORTUGAL SPAIN (E29 E53)
SEAT RMX50 1996 (T) PORTUGAL SPAIN (E29 E53)
×
prices are in EUR
ref
part #
description
quantity
1
4510003E00VE1
ref: 1
SEAT SET (VIOLET)
€ 115.00
1
4510003E0025Y
ref: 1
SEAT SET
€ 124.00
1
4510003E0034S
ref: 1
SEAT SET (BLUE)
€ 123.00
2
0932910001
ref: 2
CUSHION
€ 2.50
3
0932008029
ref: 3
CUSHION
€ 2.50
4
0932009026
ref: 4
CUSHION
€ 4.00
5
0211205103
ref: 5
SCREW
€ 2.00
6
4413203E00E0N
ref: 6
PLATE
€ 5.00
7
0916908037E0N
ref: 7
WASHER
€ 3.50
8
0713008203
ref: 8
BOLT
€ 3.00
9
4621003E00E91
ref: 9
CARRIER SET
€ 43.50
9
4621003E0025Y
ref: 9
CARRIER SET
€ 25.50
10
0713008453
ref: 10
BOLT
€ 3.00
11
0831921083
ref: 11
NUT
€ 1.50
12
0832201083
ref: 12
WASHER
€ 1.50
13
0211206203
ref: 13
SCREW, 6X20
€ 2.00
14
0832201063
ref: 14
WASHER
€ 2.00
15
0831921066
ref: 15
NUT
€ 2.00
16
4630003E00E91
ref: 16
OPT
CARRIER
€ 61.50
