REAR SWINGING ARM (MODEL M/R E17)

TS50XK 1987 (H) (E02 E16 E18 E21 E25)

Rear swinging arm (model m/r e17) diagram TS50XK 1987 (H) (E02 E16 E18 E21 E25)

prices are in EUR

ref

part #

description

quantity

610001368013L
ref: 1

SWINGING ARM ASSY, REAR (SILVER)

€ 0.00

6126113700
ref: 2

BUSHING,RR SWGARM PIVOT

€ 8.00

0928520005
ref: 3

OIL SEAL

€ 5.00

6125113700
ref: 4

SPACER,RR SWINGING ARM PIVOT

€ 19.50

6121113700
ref: 5

SHAFT,RR

€ 14.00

0832211146
ref: 6

WASHER

€ 2.00

0831921148
ref: 7

NUT 14MM

€ 3.00

6127313610
ref: 8

BUFFER,CHAIN TOUCH DEFENCE

€ 20.50

6131013690
ref: 9

CASE,CHAIN

€ 54.50

0911606096
ref: 10

BOLT(6X10)

€ 2.00

11-1

0111706105
ref: 11-1
MODEL M

BOLT, EXHAUST DRAIN

€ 2.50

11-2

0155006103
ref: 11-2
MODEL R

BOLT

€ 2.50

6134113710
ref: 12

GUIDE,CHAIN

€ 14.00

13-1

0151706164
ref: 13-1
MODEL M

BOLT

€ 2.50

13-2

0155006163
ref: 13-2
MODEL R

BOLT

€ 2.50

643114870013L
ref: 14

TORQUE LINK,RR

€ 11.50

0911108013
ref: 15

BOLT(8X26.5)

€ 3.00

0911108015
ref: 16

BOLT(8X22)

€ 3.00

0832121088
ref: 17

LOCK WASHER

€ 2.00

0914008008
ref: 18

NUT

€ 1.50

0411120208
ref: 19

PIN 20X20

€ 1.50

REAR SWINGING ARM (MODEL M/R E17)
